Aviation / Flight Video Camera Recording Systems

NEW - FC360 Aviation Systems Overview Video!



(Video courtesy www.UltralightFlyer.com)

VIDEO OF THE MONTH

Check out this great Super Cub video of our 4cam wireless system in action

hitting some river beds!!

Cessna 172 Customer taking FlightCam for a scenic view:

Flight of Solace & Introspection from Lloyd Reimer on Vimeo.

4Cam wireless video recording system goes for a ride in  a Howard 500

4Cam wireless video recording system goes for a ride in an Albatross to Greenland

4Cam wireless video recording system goes for a ride in a Howard 500 to the Grand Canyon

Reno Air Races 2011

Reno Air Races 2010

NEW for Sun n Fun 2012 - Prop Blur Lens Filter now available

NEW for 2012 -

Real Time Streaming to our 7 inch LCD via wired HDMI cable or

wireless HDMI streaming Tx/Rx!

HDMI_LCD_with_DVR_sm



What makes us different from the HD competition?

Watch this great new comparison video from FlightFlix Cameras:

http://www.flightflixcameras.com/#!video/c12uy

Motocam HD1080p vs. Drift HD170 and Drift HD

Drift_vs_MC360_sm2



ANSWERS:

1)  All of our HD systems have a wired or wireless transceiver remote control so you can turn your camera on/off at will

a)  Most competitors do not offer any sort of remote control feature

b)  The competitors that do offer a remote only control REC and don't have the ability to turn the camera on

so they waste precious battery life in "stand by" mode


2)  Our remote control is intelligent with active LED feedback of the status of your camera at all time.

a)  The competitors that do offer a remote do not have ANY light indicator to signal camera status


3)  Our systems can be internally battery powered or hardwired to the aircraft (up to 32v input)

a.)  The competition only offers battery power


4)  Our systems are waterproof to 10ft

a)  Contour GPS and Contour+ cameras are NOT waterproof


5)  Our systems come with GA or Heli audio input

a)  The competitors may offer an external mic, which is clumsy


6)  We have the correct Lens Field of View (FOV) for aviation

a)  The competition uses an ultra-wide FOV (170 degrees), which creates a fish-eyed picture and virtually eliminates

      your depth perception

b)  They use this type of lens because they only need 15-20ft of depth perception for thier

      applications (skate boarding, mountain biking, etc)

c)  Field of View and Depth perception are inversely proportional (i.e. ultra wide Field of View = low Depth of Field)

7)  Our cameras offer a Real-Time Streaming HDMI output port standard

8)  Our cameras have an integrated LCD screen to align your shot and review the footage

a)  The competition requires you to buy add-on module


WIRED SYSTEM - Great for kit builders and long flight journeys in which you

don't want to hassle with batteries

MC360-1080p4-QR-LCD_4cam4



WIRELESS SYSTEM- quick install, maximum portability

MC360-1080p4-QR-LCD-W_sm

How it works:

  • The controller can turn individual cameras on/off up to 50ft away by using 2.4Ghz transmission
  • The controller can synch all cameras on or off by using the "All On" button - great feature for video editing with time synch!
  • If the controller can not communicate with a camera due to range or noisy environment, then a 5 beep error code

           is displayed at the control box LED for the respective camera channel

  • Each camera checks in with the control box every 5 seconds to provide a "status update" by lighting the control box LED

           for the respective camera channel





aviation_web_heading_sm

A26 HD video camera mounted using a suction cup!

A26_HD_camera_install

A26_HD_camera_install2

A26_HD_camera_install3

A26_HD_camera_install4

Tested to 300 knots!

Bell 407

Bell_407_Video_System_Testing

Bell_407_LCD_Display_sm

HFS_Bell_407_Liberty_sm

HFS_Empire_State_Bldg_sm

HFS_Yankee_Stadium_sm

HFS_Heli_port_sm


1973 Cessna 182 vertical stabilizer HD video camera mount

Chilko_Lake__E._Rempel_253

HD_cam_vert_install_sm

Sieg_Vertical_Shot2

2011 YOM 2 camera video system installation

Cetus_Aero_plane

Cetus_Aero_POD_install_2_sm

Cetus_Aero_POD_install_sm

Cetus_Aero_POD_install_3_sm

Air Cam HD1080p wireless video camera install -

AirCam_Install

AirCam_Install2

AirCam_Install3

AirCam_Install5

Photos courtesy of T. Wagner

Cessna 172 HD1080p video camera install

Lloyd_install_smer

Lloyd_install_smer2

Lloyd_install_smer3

Lloyd_install_smer4

                                Super Cub HD1080p video camera install

Peter_install_smer

                 Cessna 182 HD1080p video camera install - Step Mount

Mary_install_smer

C182_camera_install

                            T34 HD1080p video camera install -

T34Camera_mount2

T34_cameramount



                                    Bush Caddy HD1080p video camera install -

bush_caddy_camera_control_box

On-board 4 camera control box (on/off with LED camera status indicators)

bush_caddy_cockpit_camera_mount

aviation cockpit  video camera mount (flat peel and stick)

bush_caddy_outside_camera_mount

aviation external video camera mount (L bracket with eyelet bolt)

bush_caddy_wing_strut_camera_mount

aviation wing strut video camera mount

bush_caddy_wing_strut_camera_mount2

Biplane HD Video System Install - Waco / Stearman

biplane4_sm

biplane5_sm

biplane_2_sm

cam_mounted3_sm_



Helicopter Blind Spot Elimination Video System

FC360_MVP_Heli_sm



View our aviation camera systems >>

Versatile Aviation Camera Systems

Our aviation camera systems are designed to work in almost any situation. Whether you need 1, 2 or 4 cameras our systems are designed

to handle the rigors of flight while retaining great quality.

Custom Installation Options

Our systems can be customized to meet almost any type of installation. By combining a base package with any of our mounts and

accessories you'll have a completely customized aerial camera system.

Durable Construction

Our helmet cams have been tested time and time again in real world situations. FlightCam 360 aviation camera systems are designed

to operate reliably in even the harshest conditions. Unlike some systems, you won't miss any details with a FlightCam 360 system.

High-Quality and Easy to Use

We combine the highest quality components with the latest camera technology to create camera systems that deliver incredible quality.

You won't have to worry about picture quality with our systems. Just turn it on and record!

Complete Systems

Spend your time filming, not picking the pieces needed to create a camera system. Our pro quality aviation camera systems will have you

up and running quickly with everything you need to start capturing footage TODAY.

View our aviation camera systems with GPS data overlay>>
